The product is simple. We’ve done all the searching, thinking and testing. The SD100 contains 1 controller-unit and 1 or 2 actuators depending on your CNC machine has 1 or 2 doors.
Introducing Safedoor SD100
Safedoor is a unique automatic door system, specially designed for robotic tending of CNC machines. The Safedoor system is also an ideal solution for CNC tending without a robot, improving operator ergonomics.
The system contains actuator(s), and a controller which together enables safe, fast and reliable operation of a CNC machine door.
With adjustable travel speed and built-in force monitoring it is capable of safe operation alongside human operators.
KEY FEATURES
- Easy installation, programming and risk assessment
- Optimized for integration with collaborative robots
- Fast and silent operation
- Automatic door size adjustment
- Force control, optimized for safe and reliable operation
- Capable for handing both single- and double door CNC machines
- Flexible mounting brackets for easy integration with different CNC machines
- Included operator panel allowing manual operation of the door and CNC machine
Your Key Benefits
One Door Solution
1 x SD100 Actuator
1 x SD100 Controller
1 x Operator panel
Mounting hardware
Two Door Solution
2 x SD100 Actuator
1 x SD100 Controller
1 x Operator panel
Mounting hardware
Fits all door-openings up to 1 m
The system automatically adjust the stroke of the actuator to fit the door.
Efficient installation process
Installation can be done quickly with everything included in the kit, adjustable brackets and smart configuration software. This allows the integrator to move on to other parts of the installation, getting production up and running faster.
Safe stop
3rd party validated safe-stop function. The stopping force and maximum traversal speed can be adjusted during installation, if required by the safety assessment.
No fingers pinched
Operator safety is crucial in all robotic applications, collaborative robotics is no exception. The weight and speed of a moving CNC door can pose a significant hazard, if the installation is not carefully plannen. The Safedoor SD100s built-in safety features and adjustable speed settings can help mitigate potential hazards.
Buy It Here
Get in touch with a distributor near you today to learn more about how the Safedoor SD100 can help automate your production.
"I can install several doors in a day, as it is very easy to install"
Henrik Jensen, Chief Integrator at Nordelektro A/S
Downloads
Safedoor Literature
The files below contain further information about the Safedoor. Namely, a quick guide through all of the components and additional material on the mechanical integration and electrical connections. They also contain more details about Safedoor’s security features as well as its warranties and certifications.
Manual
Tech-Sheet
SD100 Flyer
Supported Software Integration
Integration with different collaborative robots is made effortless through our ready-to-use software packages. These packages come with pre-made software programs, created to effectively utilise the Safedoor system.
URCAP
Quick- Guide
